| General Information |
|
Electrical Specifications |
|
| System Voltage |
48V |
Output Power Range |
5-20 kW |
| Grid Connection |
Off-grid, Hybrid Grid |
Battery Type |
LiFePO4 |
| System Type |
Wall-mounted |
Model |
48V 200Ah |
| Brand Name |
KF Solar |
Place of Origin |
Guangdong, China |
| Physical Specifications |
|
Performance & Protection |
|
| Dimensions (LWH) |
480*250*725 mm |
Weight |
125 kg |
| Type |
Split |
Communication Ports |
CAN, RS-232, RS485 |
| Protection Rating |
IP65 |
|
|
| Battery Specifications |
|
Operating Conditions |
|
| Nominal Voltage |
48V |
Operating Voltage Range |
44.0V – 57.6V |
| Nominal Capacity |
300Ah |
Max. Continuous Charge Current |
100A |
| Nominal Energy |
15.36 kWh |
Max. Continuous Discharge Current |
200A |
| Temperature Sensor Protection |
65°C |
Charge Temperature |
0°C ~ 45°C |
| Operating Temperature |
-20°C ~ 60°C |
