| Battery |
Cell Type |
LFP 314Ah / LiFePO4 314Ah (16.077 Wh / 165 Ah) |
|
|
| Battery DC Side |
Capacity & Configuration |
2570 kWh / 10×16 units |
2058 kWh / 8×16 units |
2701 kWh / 7×24 units |
|
Charge/Discharge Rate |
≤ 0.5C |
|
|
|
Depth of Discharge (DOD) |
95% |
|
|
|
Cycle Life |
8000 cycles @0.5C, 25±2°C, @70% SOH |
|
|
|
Temperature Monitoring Points |
1280 |
1024 |
1344 |
| Inverter DC Side |
Rated Current |
157A × 10 units |
157A × 8 units |
157A × 7 units |
|
Rated Power |
1285 kW |
1029 kW |
1350 kW |
| PV DC Side |
Number of Input Circuits |
20 circuits |
16 circuits |
14 circuits |
|
Rated Current per Circuit |
160A × 20 |
160A × 16 |
195A × 14 |
|
Rated Power per Circuit |
120 kW × 20 |
120 kW × 16 |
320 kW × 14 |
|
Voltage Range |
716.8 V – 921.6 V |
|
1075.2 V – 1382.4 V |
|
Rated Voltage |
819.2 V |
|
1228.8 V |
| System |
Operating Temperature |
-30 ~ 55°C (Derating above 40°C) |
|
|
|
Relative Humidity |
0 – 95% RH, non-condensing |
|
|
|
Dimensions (W × D × H) |
6058 × 2443 × 2896 mm |
|
|
|
Weight |
< 26 tons |
< 21 tons |
< 28 tons |
|
IP Rating |
IP54 (Complete Unit) |
|
|
|
Noise Level |
< 70 dB |
|
|
|
Cooling Concept |
Air-Cooled |
